ITEM / MODEL UNIT DCP-
REX-70
DCP-
REX-100
DCP-
REX-120
DCP-
REX-150
ABS.PS.
PVC.etc
ABS.PS.
PVC.etc
ABS.PS.PVC.
PE.etc
ABS.PS.PE.PET.
PC.PMMA.etc
Main Drive Motor Kw 20/40 35/75 75/120 120/190
Screw Diameter mm 70 100 120 150
Screw Length L/D 25 28 32 25 28 32 25 28 32 25 28 32
Screw Revolution r.p.m 60~120 60~120 50~100 40~100
Barrel Heating Zones   3 4 4 3 4 4 4 4 4 5 6 6
Barrel Cooling Zones   3 4 4 3 4 4 4 4 4 5 6 6
Barrel Heating Capacity Kw 18 20 39 33 40 45 55 55 55 80 80 90
Hopper Capacity L 100 120 150 200
Driving Capacity   V-Belt Drive V-Belt Drive V-Belt Drive V-Belt Drive
Extrusion Height mm 1000 1100 1100 1100
